• Chauvet Pro Rogue R1 BeamWash Moving Head
1 1

Chauvet Pro Rogue R1 BeamWash Moving Head

Chauvet Pro Rogue R1 BeamWash Moving Head

SoundPro Item: 44192 | Part Number: ROGUER1BW

$2,321.50
$2,609.00 $2,321.50
Your Price Sold out
MSRP: $2,609.00 | MAP: $2,321.50

Usually ships in 5-7 business days

  • Fully-featured RGBW LED yoke wash fixture with zoom
  • 16-bit dimming of master dimmer as well as individual colors for smooth control of fades
  • 7 RGBW LEDs, 40 W each
  • 5-pin DMX input/output connections
  • Unique lens design for excellent color blending and tight beam effects
  • Extremely fast, smooth pan and tilt movement
  • RDM enabled for remote addressing and trouble shooting
  • Selectable PWM settings for camera operation
  • User-selectable calibrated white for 7500 K at full output
  • User selectable red shift in all dimming modes to emulate tungsten fixtures
  • 6 distinct dimming modes for advanced control
  • Omega mounting bracket fits all Rogue and Maverick fixtures
  • Easy to read OLED display with simple, effective menu options
  • Simple and complex DMX channel profiles for programming versatility
Log in or register for YOUR best price

Rogue R1 BeamWash is a versatile and compact moving head that projects a punchy beam and wash. Weighing just under 12 lbs., the unit features a custom-designed optical system with seven, 40W RGBW LEDs and an expansive zoom range of 3.4° to 67.7° that allows for it to project tight, solid beam effects at its most narrow and transforms the light source into a nice even wash with excellent color blending as it expands. The unit’s small size also allows for a superfast and smooth pan and tilt movement. It’s also RDM enabled for remote addressing and is equipped with a selectable PWM setting to maintain flicker free operation on camera.

View full details
  • Optical
    • Light Source: 7 LEDs (quad-color RGBW) 40 W, (980 mA), 50,000 hours life expectancy
    • Color Temperature (range): 2800 to 10000 K
    • Beam Angle: 4° to 37.8°
    • Field Angle: 5° to 58.2°
    • Cutoff Angle: 5.5° to 67.7°
    • Zoom Range: 3.4° to 67.7°
    • Lumens – Source: 5,400
    • Lumens – Output: 3,967 Wide
    • Illuminance (5°): 13,939 lux @ 5 m
    • Illuminance (55°): 383 lux @ 5 m
    • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
  • Dynamic Effects
    • Pan and Tilt: 540°/230°
    • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 230° tilt
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Zoom: Motorized
    • Strobe Rate: 0 to 20 Hz
    • Standalone Color Mixing: Yes
    • Color Temperature Presets: Yes
    • Dim Curves: 4
    • Built-in Automated Programs: Yes
    • Customizable Programs: No
    • Recall Custom Programs: No
  • Construction/Physical
    • Dimensions: 8.42x6.29x14.52" (214x160x369 mm)
    • Weight: 11.8 lbs (5.35 kg)
    • Exterior Color: Black
    • Housing Material: High-impact flame-retardant polymer
  • Connections
    • Power Connection: Edison (Local) plug to Neutrik® powerCON®
    • Power Input: Neutrik® powerCON®
    • Power Output: Neutrik® powerCON®
    • Data Connectors: 5-pin XLRCable Length (power): 5 ft (1.5 m)
  • Control
    • Control Protocol: DMX
    • DMX Channels: 14, 15, 19 or 21
    • Modes/Personalities: 4 personalities (14, 15, 19, 21)
  • Electrical
    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power Linking: 5 units @ 120 V; 9 units @ 208 V; 11 units @ 230 V
    • Power and Current: 285 W, 2.38 A @ 120 V, 60 Hz
    • Power and Current: 285 W, 1.37 A @ 208 V, 60 Hz
    • Power and Current: 284 W, 1.23 A @ 230 V, 50 Hz
  • Certifications/Qualifications
    • CE, MET
    • IP Rating: IP20, dry location
