Community IP8-1152 15-Inch Surface Mount Install Speaker | Color: White, Nominal Beamwidth: 90 x 40

Community IP8-1152 15-Inch Surface Mount Install Speaker | Color: White, Nominal Beamwidth: 90 x 40

SoundPro Item: 11604 | Part Number: IP8-1152/94W

Regular price $3,632.00
Regular price $3,632.00 Sale price $3,632.00
Your Price Sold out
MSRP: $3,632.00 | MAP: $3,632.00

Usually ships in 5-7 business days

  • High-flux, linear neodymium motors with demodulation rings for very low distortion
  • Exceptional sound quality and clarity at very high output levels
  • Lightweight and compact with deep LF extension
  • Large rotatable waveguide with individually voiced crossover, single amp / biamp selectable
  • Innovative low profile modular bracket systems create elegant arrays with simplified installation
  • Colors available: black, white (not pictured).

The Community IP8-1152 15-Inch Surface Mount Install Speaker provides exemplary acoustic performance, modular flexibility and elegant aesthetics for modern performance venues. Designed to support the goals of systems integrators and consultants both acoustically and mechanically, I SERIES includes a wide variety of arrayable, rotatable coverage patterns and a comprehensive selection of modular bracket systems that accelerate system design and system commissioning.

FEA-optimized linear suspensions, high-flux neodymium motors, and integral demodulation rings ensure precise control and very low distortion at high SPL levels. The custom long-excursion LF driver delivers deep bass response and a balanced midrange in the most demanding applications. The HF compression driver's non-metallic diaphragm provides natural, transparent sound quality that accurately reproduces and complements any source.

The rotatable 13-inch (330mm) HF waveguide provides well-defined coverage and a smooth off-axis response that enhances arrayability. Individually voiced crossovers produce proper beamwidth matching transitions and identical sonic signatures, permitting horn patterns to be mixed throughout an installation. Additionally, user selectable single amp or biamp operating modes expand application flexibility.

View full details
  • Operating ModePassive or Biamp with DSP
  • Operating Environment Indoor or Weather-Resistant Outdoor
  • Operating Range[2]31 Hz to 19 kHz
  • Nominal Beamwidth (HxV) 60°x40°, rotatable waveguide
  • Transducers
    • LF 1 x 15" (381mm) neodymium driver, 3" (76mm) voice coil, demodulation ring
    • HF 1 x 1.4" (36mm) exit compression, 2.6" (66mm) voice coil, demodulation ring, ketone polymer diaphragm, neodymium compression driver
  • Continuous Power Handling [3] @ Nominal Impedance
    • Passive* - 80V: 800W @ 8 ohms (3200W peak)
    • LF - 69V: 600W @ 8 ohms (2400W peak)
    • HF - 25V: 80W @ 8 ohms (320W peak)
  • Nominal Sensitivity [4]
    • Passive
      • @ 1W: 94 dB
      • @ 2.83V: 94 dB
    • LF
      • @ 1W: 95 dB
      • @ 2.83V: 95 dB
    • H
      • @ 1W: 108 dB
      • @ 2.83V: 108 dB
  • Nominal Maximum SPL[5] (Whole Space)
    • Passive
      • Peak: 129dB
      • Continuous: 123 dB
    • LF
      • Peak: 129 dB
      • Continuous: 123 dB
    • HF
      • Peak: 133 dB
      • Continuous: 127 dB
  • Equalized Sensitivity[6]
    • System
      • @ 1W: 94 dB
      • @ 2.83V: 94 dB
  • Equalized Maximum SPL[7]
    • System
      • Peak: 129 dB
      • Continuous: 123 dB
  • Recommended Amplifiers
    • Passive: 800W - 1600W @ 8 ohms, (80V - 113V)
    • LF: 600W - 1200W @ 8 ohms, (69V - 98V)
    • HF: 80W - 160W @ 8 ohms (25V - 36V)
  • PHYSICAL
    • Input Connection: (2) Screw terminal blocks (6-position)
    • Mounting Points: (15) M10 threaded rigging points
    • Environmental: Outdoor - IP55W per IEC 60529 , MIL-STD-810G
    • Weight: 68 lbs (30.8 kg) loudspeaker only
    • Dimensions (HxWxD): 30.8x16.5x20.07" (782x419x510mm)
    • Finish Refer to the Technical Drawing
