- Operating ModeSingle Amp
- Operating EnvironmentIndoor or Weather-Resistant Outdoor
- Operating Range[2] 32 Hz to 145 Hz
- Transducers 1 x 18" (457mm) double-treated cone with 4" (102mm) inner/outer wound voice coil, ferrite construction
- Continuous Power Handling [3] @ Nominal ImpedanceSingle Amp: 75V; 700W @ 4 ohms (28000W peak)
- Nominal Sensitivity[4]
- Half Space: 104 dB @ 1W; 104 dB @ 2.83V
- Whole Space: 98 dB @ 1W; 98 dB @ 2.83V
- Nominal Maximum SPL[5]
- Half Space Peak: 138 dB; Continuous: 132 dB
- Whole Space Peak: 132 dB; Continuous: 126 dB
- Equalized Sensitivity[6]
- Half Space: 99 dB @ 1W; 99 dB @ 2.83V
- Whole Space: 93 dB @ 1W; 93 dB @ 2.83V
- Equalized Maximum SPL[7]
- Half Space Peak: 133 dB; Continuous: 127 dB
- Whole Space Peak: 127 dB; Continuous: 121 dB
- Recommended AmplifiersSingle Amp: 700W - 14000W @ 4 ohms, (75V - 106V)
- Physical
- Input Connection: (2) Screw terminal blocks (4-position)
- Mounting Points: (24) M10 threaded rigging points Indoor; (22 in Outdoor model)
- Environmental: Outdoor: IP55W per IEC 60529 , MIL-STD-810G
- Weight: 97 lbs (44 kg) subwoofer only
- Dimensions (HxWxD) 19.8x22.1x28.89" (503x561x734 mm)
