- Operating ModeSingle
- Operating EnvironmentIndoor or Weather-Resistant Outdoor
- Operating Range[2] 36 Hz to 155 Hz
- Transducers 1 x 15" (381mm) double-treated cones with 4" (102mm) voice coil, demodulation ring, neodymium construction
- Continuous Power Handling [3] @ Nominal ImpedanceSingle Amp: 89V; 1000W @ 4 ohms (4000W peak)
- Nominal Sensitivity[4]
- Half Space: 99 dB @ 1W; 99 dB @ 2.83V
- Whole Space: 93 dB @ 1W; 93 dB @ 2.83V
- Nominal Maximum SPL[5]
- Half Space Peak: 135 dB; Continuous: 129 dB
- Whole Space Peak: 129 dB; Continuous: 123 dB
- Equalized Sensitivity[6]
- Half Space: 97 dB @ 1W; 97 dB @ 2.83V
- Whole Space: 91 dB @ 1W; 91 dB @ 2.83V
- Equalized Maximum SPL[7]
- Half Space Peak: 133 dB; Continuous: 127 dB
- Whole Space Peak: 127 dB; Continuous: 121 dB
- Recommended AmplifiersSingle Amp: 1000W - 2000W @ 4 ohms, (75V - 106V)
- Physical
- Input Connection: (2) Screw terminal blocks (4-position)
- Mounting Points: (24) M10 threaded rigging points Indoor; (22 in Outdoor model)
- Environmental: Outdoor: IP55W per IEC 60529, MIL-STD-810G
- Weight: 72 lbs (32.7 kg) subwoofer only
- Dimensions (HxWxD) 19.8x16.5x23.35" (503x419x593 mm)
