- Frequency Response50 Hz to 18 kHz
- Polar PatternHypercardioid
- Operating Current500 uA
- Operating Voltage1 to 2 Volts
- Power Supply Voltage
- +3V with 2.7 kOhm load
- +5V with 6.8 kOhm load
- +9V with 15 kOhm load
- Weight0.22 oz (6.2 g) without connector
- Sensitivity
- W4 (standard, gray band): 6.0 mV/Pa (-44 dB re 1V/Pa)
- W5 (mid, red band): 2.0 mV/Pa (-54 dB re 1V/Pa)
- W6 (low, blue band): 0.7 mV/Pa (-63 dB re 1V/Pa)
- Equivalent Acoustic Noise
- W4: 34 dBA
- W5: 39 dBA
- W6: 44 dBA
- Overload Sound Level
- W4: 120 dB SPL
- W5: 130 dBA SPL
- W6: 140 dBA SPL
- Cable Length5 Feet
