Specifications
Dimensions
Capsule Dimensions
0.23" x 0.18" (5.8mm x 4.6mm)
Weight
Mic Weight
0.012 oz (0.34 g)
Electrical
Power Requirements (Wireless)
3V to 12V at 200 uA
Power Requirements (Phantom)
9V to 48V (4mA at 48V)
Phantom
9V to 48V (4mA at 48V)
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity (W4, no band)
12.0 mV/Pascal (-38 dB re 1V/Pa)
Sensitivity (W5, red band)
4.0 mV/Pascal (-48 dB re 1V/Pa)
Equivalent Acoustic Noise
24 dBA
Overload Sound Level (Wireless)
140 dBA SPL (5V, red band)
Overload Sound Level (Phantom)
150 dBA SPL (48V, red band)
Construction
Cable Length
5 Feet
Cable Diameter
2mm
Cable Material
Duramax Aramid-Reinforced
Color
Black
Connector
TA4F
Gain
Standard Gain
Compatibility
Compatible Shure Models
AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125 in x 5.125 in x 1.375 in
Shipping Weight
0.75 lbs
Weight
0.012 oz (0.34 g)
Identifiers
MPN
B3W4FF05BAX
General
Transducer Type
Condenser
