Specifications
Weight
Microphone Weight
0.07 oz (2 g)
Shipping Weight
0.75 lbs
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity (W4 Standard, Gray Band)
16.0 mV/Pa (-36 dB re 1V/Pa)
Sensitivity (W5 Mid, Red Band)
7.0 mV/Pa (-43 dB re 1V/Pa)
Sensitivity (W6 Low, Blue Band)
2.0 mV/Pa (-54 dB re 1V/Pa)
Equivalent Acoustic Noise (W4)
24 dBA
Equivalent Acoustic Noise (W5)
29 dBA
Equivalent Acoustic Noise (W6)
39 dBA
Overload Sound Level (W4)
120 dB SPL
Overload Sound Level (W5)
130 dBA SPL
Overload Sound Level (W6)
140 dBA SPL
Connectivity
Connector Type
TA4F
Detachability
Detachable
Construction
Cable Length
5'
Cable Diameter
1.25mm
Cable Material
Aramid-Reinforced
Color
Cocoa
Compatibility
Shure
BLX1, FP1, PG1, SLX1, UC1, ULX1, UR1, UR1M
Carvin
UBP1000, UX16-BP, UXBP16
JTS
E-6TB, E-7TB(D), IN264TB, IN64TB, PG-36BG2, PT-850B, PT-850BD, PT900B, PT-920B, PT-920BG, PT-920BGmi, PT-920Bmi, PT-950, PT-950Bmi, RU-850LTB, RU-850TB, RU-988TB, RU-G3TB, UF-10TB, UF-20TB
Trantec
S4.4-BTX, S5.3-BTX, S5.5-BTX
Beyerdynamic
TG 1000 (gray switch), TG 100B (gray switch)
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
General
Transducer Type
Condenser
W4
24 dBA
W5
29 dBA
W6
39 dBA
