Specifications
Weight
Microphone Weight
0.07 oz (2 g)
Shipping Weight
0.75 lbs
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity (W5 Mid)
7.0 mV/Pa (-43 dB re 1V/Pa)
Equivalent Acoustic Noise (W5)
29 dBA
Overload Sound Level (W5)
130 dB SPL
Connectivity
Connector Type
Hirose 4 pin (AT)
Detachability
Detachable
Construction
Cable Length
5'
Cable Diameter
1.25mm
Cable Type
Aramid-Reinforced
Color
Cocoa
Compatibility
Compatible Transmitters
Audio Technica ATW-T1801, ATW-T201, ATW-T210, ATW-T210a, ATW-T27, ATW-T31, ATW-T310, ATW-T310b, ATW-T51
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
Identifiers
MPN
B6W5FF05CDAT
General
Transducer Type
Condenser
W4 (standard, Gray band)
16.0 mV/Pa (-36 dB re 1V/Pa)
W5 (mid, Red band)
7.0 mV/Pa (-43 dB re 1V/Pa)
W6 (low, Blue band)
2.0 mV/Pa (-54 dB re 1V/Pa)
W4
24 dBA
W5
29 dBA
W6
39 dBA
