Specifications
Weight
Product Weight
0.07 oz (2 g)
Shipping Weight
0.75 lb
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity (W7, Purple Band)
0.6 mV/Pascal
Equivalent Acoustic Noise (W7)
39 dBA
Overload Sound Level (Directional W7)
145 dBA SPL
Connectivity
Connector Type
TA4F (AX)
Construction
Pickup Pattern
Directional
Boom Style
Classic/Springy
Cable Diameter
1mm
Cable Material
Aramid-Reinforced
Cable Length
5 Feet
Color
Tan
Compatibility
Compatible Transmitters
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
Identifiers
MPN
E6DW7T1AX
General
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
