Specifications
Weight
Product Weight
0.07 oz (2 g)
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W5 (No Band)
6.0 mV/Pascal
Sensitivity W6 (Blue Band)
1.9 mV/Pascal
Sensitivity W7 (Purple Band)
0.6 mV/Pascal
Equivalent Acoustic Noise W5
24 dBA
Equivalent Acoustic Noise W6
29 dBA
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level W5
125 dBA SPL
Overload Sound Level W6
135 dBA SPL
Overload Sound Level W7
145 dBA SPL
Construction
Cable Length
5 Feet
Cable Diameter
2mm
Cable Type
Duramax Aramid-Reinforced
Connector
TA4F
Boom Flexibility
Flexible boom and springy ear section
Color
Black
Polar Pattern
Directional
Gain
Standard gain for general speaking
Compatibility
Compatible Transmitters
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
Weight
0.07 oz (2 g)
General
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
