Specifications
Weight
Product Weight
0.07 oz (2 g)
Shipping Weight
0.75 lb
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Polar Pattern
Directional
Frequency Response
30 Hz to 15 kHz
Sensitivity (W7, Purple Band)
0.6 mV/Pascal
Equivalent Acoustic Noise (W7)
39 dBA
Overload Sound Level (W7)
145 dBA SPL
Connectivity
Connector Type
TA4F
Construction
Cable Diameter
1mm
Cable Length
5 Feet
Cable Type
Aramid-Reinforced
Color
Tan
Compatibility
Compatible Transmitters
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
Identifiers
MPN
E6XDW7T1AX
General
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
