Specifications
Weight
Product Weight
0.07 oz (2 g)
Shipping Weight
0.75 lbs
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Polar Pattern
Omnidirectional
Frequency Response
20 Hz to 20 kHz
Sensitivity (W5, No Band)
7.0 mV/Pascal
Sensitivity (W6, Blue Band)
2.0 mV/Pascal
Sensitivity (W7, Purple Band)
0.7 mV/Pascal
Equivalent Acoustic Noise (W5)
24 dBA
Equivalent Acoustic Noise (W6)
29 dBA
Equivalent Acoustic Noise (W7)
39 dBA
Overload Sound Level (W5)
120 dB SPL
Overload Sound Level (W6)
130 dB SPL
Overload Sound Level (W7)
140 dB SPL
Connectivity
Connector
TA4F
Compatible Transmitters
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Construction
Boom Style
Flexible boom and springy ear section
Cable Diameter
1mm
Cable Type
Aramid-Reinforced
Color
Black
Cable Length
5 Feet
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
Identifiers
MPN
E6XOW5B1AX
General
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
