Specifications
Weight
Product Weight
0.07 oz (2 g)
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Omnidirectional)
20 Hz to 20 kHz
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W6 Omnidirectional (Blue Band)
2.0 mV/Pascal
Sensitivity W5 Omnidirectional (No Band)
7.0 mV/Pascal
Sensitivity W7 Omnidirectional (Purple Band)
0.7 mV/Pascal
Sensitivity W6 Directional (Blue Band)
1.9 mV/Pascal
Sensitivity W5 Directional (No Band)
6.0 mV/Pascal
Sensitivity W7 Directional (Purple Band)
0.6 mV/Pascal
Equivalent Acoustic Noise W5
24 dBA
Equivalent Acoustic Noise W6
29 dBA
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level Omnidirectional W5
120 dB SPL
Overload Sound Level Omnidirectional W6
130 dBA SPL
Overload Sound Level Omnidirectional W7
140 dBA SPL
Overload Sound Level Directional W5
125 dBA SPL
Overload Sound Level Directional W6
135 dBA SPL
Overload Sound Level Directional W7
145 dBA SPL
Construction
Cable Diameter
1mm Aramid-Reinforced Cable
Cable Length
5'
Pattern
Omnidirectional
Connector
TA4F (AX)
Color
Black
Boom Style
Flexible boom and springy ear section
Compatibility
Shure Transmitters
AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125 in x 5.125 in x 1.375 in
Shipping Weight
0.75 lbs
Weight
0.07 oz (2 g)
General
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
