- Frequency response±0.25dB (8Ω, 20Hz - 20kHz)
- Dante input signal to noise ratio>108dB (ref rated power, 8ohm, 20Hz-20kHz)
- THD0.35% (at full rated power, 20Hz-20kHz)
- Voltage gain34dB (at max level setting)
- Damping factor>1500 (20Hz to 100Hz)
- Input impedance (nominal balanced, unbalanced)10kΩ, 5kΩ
- Max input level before compression+20dBu (low gain mode)
- Load impedance stereo/dual mode2Ω - 16Ω; 70Vrms and 100Vrms
- Load impedance bridge mono4Ω - 16Ω; 140Vrms and 200Vrms
- Coolingcontinuously variable speed forced air, front to back airflow
- Max fan noise47 (re dBA SPL @ 1M)
- Required AC mains (+/-10%)100Vrms - 240Vrms~50/60Hz
- IEC power connector20A
- Dimensions19" x 3.5" x 17"
- Weight30 pounds (13.6 kg)
