- Frequency response20 Hz - 20 kHz, +0/-1 dB (at 1 watt)
- THD<0.5%, 20 Hz - 20 kHz
- Intermodulation distortion=/ <0.35% (60 Hz and 7 kHz at 4:1 from full rated ouput to -30 dB)
- Slew rate>10V/us
- Voltage gain33 dB
- Damping factor(8 ohms, 10 Hz to 400 Hz) >200
- Signal to noise ratio (A-weighted)>100 dB
- Crosstalk (below rated power) 20Hz to 1kHz-75 dB, -59 dB
- Input sensitivity0.775V or 1.4V (for full rated power at 8 ohms)
- Input impedance20kΩ (nominal balanced), 10kΩ (unbalanced)
- AC line voltage and frequency configurations(+10%) 120V~60 Hz; 220V~50/60 Hz; 230-240V~50/60 Hz
- IEC power connector15A
- Dimensions19" x 3.5" x 12.4"
- Weight29.7 pounds (13.5 kg)
