Specifications
Performance
Frequency Range (-10 dB)
50 Hz – 20 kHz
Nominal Impedance
8 ohms
Conical Coverage
90º
RMS Power Handling
60 W
Peak Power Handling
240 W
On-axis Sensitivity 1W/1m
90 dB SPL
Maximum Peak SPL at 1m
114 dB
Recommended Amplifier
INTEGRAL-A402 INTEGRAL-A404 INTEGRAL-A1002 INTEGRAL-A1004 INTEGRAL-A1602 INTEGRAL-A1604 INTEGRAL-MA1004 INTEGRAL-MA1604
Recommended Processor
INTEGRAL-M88 INTEGRAL-MA1604 INTEGRAL-MA1004
Connectivity
Audio Input Connector
Spring Terminals
Audio Output Connector
Spring Terminals
Dimensions
Enclosure Geometry
Round
Cut Out Diameter
250 mm (9.9 in)
Enclosure Dimensions (H x W x D)
285 x 285 x 115 mm (11.3 x 11.3 x 4.6 in)
Carton Dimensions (H x W x D)
310 x 300 x 450 mm (12.2 x 11.8 x 17.7 in)
Weight
Net Weight
1.6 kg (3.5 lb)
Shipping Weight
1.8 kg (4.0 lb)
Construction
Color
White
Materials
Cone Material
Polypropylene
