Specifications
- Inputs2
- Input connectorsfemale XLR and 1/4” TRS
- Input typeelectronically balanced/unbalanced, RF filtered
- Input impedancebalanced 50kΩ, unbalanced 25kΩ
- Max input line level+20 dBu
- CMRR> 40dB, typically >55dB @ 1kHz
- Outputs2
- Output connectorsmale XLR and 1/4” TRS
- Output typeelectronically balanced/unbalanced, RF filtered
- Output impedancebalanced >120 Ω, unbalanced >60 Ω
- Max output level+20 dBu
- A/D converterType IV™ Conversion System
- A/D dynamic range>113 dB A-weighted, >110 dB unweighted, 22kHz BW
- A/D conversion24-bit
- Sample rate48kHz
- D/A dynamic range112 dB A-weighted, 109 dB unweighted
- D/A conversion24-bit
- Dynamic range109 dB A-weighted, 106 dB unweighted, 22kHz BW
- THD+Noise0.003% typical at +4 dBu, 1 kHz
- Frequency response20Hz – 20kHz, +/- 0.5dB
- Interchannel crosstalk>80 dB typical
- Operating voltage100-120VAC 50/60 Hz
- Power consumption9W
