Specifications
Performance
Frequency Response
55HZ–18kHz
Max SPL
140 dB
Operating Mode
Bi-amp LF,HF
Drivers
LF
2×10″ cone, 2.5″ VC Vented
HF
1×1.4″ exit, 3″ VC compression drivers Isophasic Wave Guide
Coverage
Horizontal
90°
Vertical
12°
Power Handling
LF
1200W
HF
400W
Connections
AC Mains
Neutrik PowerCON TRUE1 TOP
Network
Ethernet/Dante
Audio
XLR/Analog
Dimensions
Height
12.3in (314mm)
Width
28.3in (720mm)
Depth
20.5in (520mm)
Weight
64Ibs
