- Projection System3LCD, 3-chip technology
- Projection Method Front/rear/ceiling mount
- Driving Method Poly-Silicon TFT Active Matrix
- Pixel Number 786,432 dots (1024 x 768) x 3
- Color Brightness2 Color Light Output: 3,400 lumens
- White Brightness2 White Light Output: 3,400 lumens
- Aspect Ratio 4:3
- Native Resolution 1024 x 768 (XGA)
- Resize 1280 x 800 (WXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3) 1366 x 768 (WXGA60-3), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+)
- Lamp Type 210 W UHE
- Lamp Life3
- ECO Mode: Up to 12,000 hours
- Normal Mode: Up to 6,000 hours
- Throw Ratio Range 1.44 (Zoom: Wide), 1.95 (Zoom: Tele)
- Size (Projected Distance) 30" to 350" (0.87 to 10.34 m) (Zoom: Wide)
- Keystone Correction
- Vertical: ± 30 degrees (Automatic)
- Horizontal: ± 30 degrees (Slider)
- USB Plug ’n Play Projector is compatible with PC and Mac® computers
- Contrast Ratio Up to 15,000:1
- Color Reproduction Up to 1.07 billion colors
- Projection Lens
- Type Manual focus
- F-number 1.44
- Focal Length 16.7 mm
- Zoom Ratio Digital zoom 1.0 – 1.35
- Other
- Display Performance NTSC: 480 lines, PAL: 576 lines (depends on observation of the multi-burst pattern)
- Input Signal NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/ SECAM
- Speaker 5 W (mono)
- Operating Temperature 41 ° to 95 °F (5 ° to 35 °C) high altitude, 41 ° to 104 °F (5 ° to 40 °C) low altitude
- Power Supply Voltage 100 – 240 V AC ±10%, 50/60 Hz
- Power Consumption
- ECO Mode: 235 W
- Normal Mode: 345 W
- Standby: Max. 2.0 W
- Fan Noise
- ECO Mode: 28 dB
- Normal Mode: 37 dB
- Security Kensington-style lock provision, padlock and security anchor bar
- Interfaces
- 1x USB Type-B
- 1x HDMI
- 2x Computer/Component
- 1x Video
- 1x RS-232c
- 1x Monitor Out
- Audio 1 & 2
