Specifications
Audio Performance
Mic Sensitivity
-37 dBV ± 2dB @ 1 KHz, 94dB SPL
Frequency Response
20 Hz–20 kHz
Signal-to-Noise Ratio
> 70dB
Sound Pressure Level
115dB SPL
Mic Polar Pattern
Omnidirectional
Sample Rate
48 kHz
Bit Depth
24-bit
Wireless Transmission
Wireless Transmission
2.4 GHz Adaptive Frequency Hopping (AFH)
Wireless Modulation Mode
GFSK 2 Mbps
Transmission Range
Up to 1000ft (300m) for LOS/130ft (40m) for NLOS
Power
TX Battery Capacity
97 mAh
Camera RX Battery Capacity
145 mAh
Charging Case Battery Capacity
1950 mAh
TX Operating Time
About 10 hours
Camera RX Operating Time
About 9 hours
Charging Case Capacity
> 3 times charging for all TX and RX at the same time
TX Charging Time
About 1.5 hours
Camera RX Charging Time
About 1.5 hours
Charging Case Charging Time
< 2 hours
TX Battery Voltage
3.87V
Camera RX Battery Voltage
3.87V
Charging Case Battery Voltage
3.8V
Environmental
Operating Temperature
-10° C to 45° C
Charging Temperature
0° C to 45° C
Dimensions
TX Dimensions
D26mm x 9.9mm (1.0" x 0.4")
Camera RX Dimensions
40mm x 25.7mm x 20.5mm (1.6" x 1.0" x 0.8")
Charging Case Dimensions
86mm x 54mm x 39mm (3.4" x 2.1" x 1.5")
Weight
TX Weight
9g (0.3oz)
Camera RX Weight
14.8g (0.5oz)
Charging Case Weight
111g (3.9oz)
Included Items
Transmitters
2
Camera Receiver
1
Charging Case
1
TX Windscreens
2
USB-A to USB-C Cable
1
USB-C to USB-C Cable
1
USB-C to Lightning Cable
1
3.5mm TRS to 3.5mm TRS Cable
1
Clip Magnets
4
Back Clips
2
Necklace Silicone Cases
2
TX Stickers
1
Quick Guide
1
Warranty Card
1
