Specifications
Dimensions
Dimensions (WxHxD)
28.35" x 12.6" x 20.47"
Audio
Speaker Type
2-way active line array module
Frequency Response
78-18,000Hz (+/-3dB)
Max SPL
135dB
Connectivity
Signal Input
1x XLR fem balanced
Signal Output
1x XLR male balanced
Network
RDNet remote control RJ45 connector IN/OUT
Power Socket
1x PowerCON TRUE1 IN, 1x PowerCON TRUE1 OUT
Shipping
Weight
63 pounds (28.6 kg)
General
Usable Bandwidth
67-20,000Hz (-6dB)
HF
1x 1.4"
Voice Coil HF
3"
Type HF
neodymium, titanium diaphragm
LF
2x10"
Voice Coil LF
2.5"
Type LF
neodymium aluminum phase plug
Horizontal Directivity
100°
RMS Power
900W
Peak Power
1800W
Power Supply
900W SMPS with Auto-range PSU
Controller
DSP 56 bit
AD/DA Converter
24 bit / 48kHz
Limiter
Dual Active Multiband Peak, RMS, Thermal
Processing Filters
FIR Linear Phase
Crossover Frequency LF-HF
950Hz
Slope LF-HF
24dB/Octave
