• JBL SRX815 Passive Portable PA Speaker
1 1

JBL SRX815 15-Inch Passive Speaker

JBL SRX815 15-Inch Passive Speaker

Soundpro Item: 72727 | Part Number: SRX815

$1,439.00
$1,655.00 $1,439.00
Your Price Sold out
MSRP: $1,655.00 | MAP: $1,439.00

Usually ships in 5-7 business days

  • Premium JBL Transducers with extremely high power handling
  • Rugged, versatile enclosures
  • Full Integration into Audio Architect
  • Maximum SPL Output: 136dB
  • System Type: Passive 15", two-way, bass-reflex
  • Frequency Range (-10dB): 41Hz - 20kHz
  • Frequency Response (- 3dB): 56Hz - 20kHz
  • Coverage Pattern: 90 x 50
  • JBL Professional Tunings available for Crown Itech HD
  • M10 Suspension Points
  • Dual Angle 36mm pole cup
  • Feet for monitor angle
  • Lightweight poplar plywood cabinets made structurally sound with tongue and groove joints and protected by JBL's tour proven DuraFlex™ finish
Log in or register for YOUR best price

The SRX815 is a passive portable PA speaker in the SRX800 series from JBL Professional. It has been designed to deliver class leading performance in a variety of applications including use as a main PA, a stage monitor, and rear and side fills. When used in conjunction with the other SRX800 full range systems and the SRX800 subs, SRX815 in an integral part of a high performance, fully configurable loudspeaker system.

View full details

Specifications

  • System Type Passive 15”, two-way, bass-reflex
  • Maximum SPL Output 124dB (Continuous), 130dB (Peak)
  • Frequency Range (-10dB) 41hz - 20khz
  • Frequency Response (-3 dB) 56hz - 20khz
  • Sensitivity 95dB
  • System Power Rating 3200W Peak, 1600W Program, 800W Continuous
  • Nominal Impedance 8 Ohm
  • Inputs NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable)
  • Operational Modes Passive/Bi-Amp
  • LF Driver 2275H
  • HF Driver 2432H
  • Coverage Pattern 90 x 50
  • Crossover Frequency 1.9khz
  • Enclosure 18mm Duraflex coated plywood
  • Monitor Angle 50°
  • Suspension/Mounting Dual 36mm pole socket, 12 x M10 Suspension points
  • Handles 3
  • Finish Obsidian Duraflex™ finish
  • Grille Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
  • Dimensions (H x W x D)18.82 x 18.03 x 27.2 inches (478 x 458 x 691mm)
  • Weight 57 lbs (25.9kg)
  • Shipping Weight 67 lbs (30.4kg)
