JBL VRX928LA 8-Inch Passive Line Array Speaker | Color: Black
JBL VRX928LA 8-Inch Passive Line Array Speaker | Color: Black
SoundPro Item: 47400 | Part Number: VRX928LA
Usually ships in 5-7 business days
- JBL's exclusive neodymium magnet Differential Drive® woofer for highpower capacity and lightweight
- Two patent-pending neodymium HF compression drivers
- Constant Curvature waveguide for unprecedented array coherence
- Integral rigging hardware for simple connection of enclosures and optional array frame
- Arrays of up to six enclosures may be flown
- Dual angle pole socket for aiming flexibility. One or two speakers may be mounted to a 35 mm pole or tripod stand
- Array Configuration Selector permits "array shading" in passive mode
The VRX928LA is a lightweight compact 8" two-way line array speaker system designed for use in arrays of up to six units. VRX928LA is the ideal choice when line-array performance is needed but the venue size doesn't call for the very long-throw characteristics of larger line-arrays.
The Constant Curvature waveguide mounts two compression drivers on a continuous arc. When additional VRX928LA speakers are added to the array the uninterrupted arc continues. In effect, all the drivers work together as if they were a single driver on a very long waveguide. Since there are two HF drivers in each VRX928LA, the combined power handling and acoustic output of the system is far greater than a single driver could achieve.
- Power Rating 400 W / 800 W / 1600W
- Frequency Range (-10dB) 70 Hz - 20 kHz
- Dimensions (HxWxD) 9x16.5x10.5" (230x420x270mm)
- Coverage Pattern 100 x 15 nominal
- Frequency Response (±3 dB) 85 Hz - 19 Hz
- Crossover Modes Bi-amp / passive
- Crossover Frequency 2.0 kHz
- Net Weight (each) 12.7 kg (28 lb)
- Inputs Neutrik® Speakon NL-4 (x2)
- Outputs 1 x XLR
- Enclosure Duraflex coated plywood
- System Type Constant Curvature 8" Two-Way Line Array System
- Maximum SPL (1m) 122 dB SPL peak (passive mode) LF: 122 dB (bi-amp mode) HF: 128 dB (bi-amp mode)
- Nominal Impedance
- Passive = 8 ohm
- Bi-amp LF = 8 ohm
- Bi-amp HF = 16 ohm
- LF Driver 1 x 200 mm (8 in) Differential Drive® woofer
- HF Driver 2 x 25 mm (1 in) neodymium compression driver
- Suspension / Mounting Dual 36 mm pole socket included. Suspension requires optional VRX-SMAF line array frame kit or M10 eyebolts.
