- Product typeStage monitors
- TypePowered
- ColorBlack
- System output (RMS) 300W
- System output (Peak) 1200W
- Max. SPL Average (Sine burst) 116 dB ( 100Hz - 12 kHz, fullspace @1m, 10% THD )
- Max. SPL Peak (Sine burst) 121 dB ( fullspace @1m, 10% THD )
- Frequency response (-3 dB) 68 Hz - 18000 Hz
- Frequency response (-10 dB) 59 Hz - 20000 Hz
- Crossover frequency2500 Hz
- Monitor angle33°
- Dispersion (H x V) 50° x 90°
- Width340 mm
- Depth368 mm
- Height278 mm
- Features3-band EQ (High, Mid, Low), 4 Application presets, Delay line, Notch filter
- Weight13,2 kg
- Low/mid woofer
- Low/mid Woofer dimensions: 8"
- Woofer dimensions: 203.2 mm
- Woofer magnet: Ferrite
- Woofer brand: Custom-made
- Woofer type: Coaxial loudspeaker
- Woofer voice coil: 2.5"
- Woofer voice coil: 65 mm
- Cabinet construction: Bass Reflex
- Cabinet material: 15 mm Birch Plywood, 15 mm MDF
- HF
- Horn: CD Horn
- Tweeter dimensions: 1"
- Tweeter dimensions: 25.4 mm
- Tweeter magnet: Ferrite
- Tweeter brand: Custom-made
- Tweeter voice coil: 1.75 "
- Tweeter voice coil: 44.45 mm
- Amplifier module (integrated)
- Amplifier: Class D
- Protection circuits: Multiband limiter, over voltage, over-current, thermal overload
- Operating Temperature: 0 - 40°C
- Humidity Range: < 80 % ( non-condensing )
- Fuse: T4AL 250V
- Controls: On / off switch, Rotary/push encoder
- Indicators: LC display
- Operating voltage: SMPS
- Operating voltage: 100 V AC - 240 V AC, 50 - 60 Hz
- Power consumption: 150W
- Power in / out: PowerCON compatible
- Line inputs: 2
- Line input connectors: 6.3 mm jack, XLR - combo
- Line thru: 2
- Line through connector: XLR
