- Main Mix Noise
- 20Hz - 20kHz bandwidth, 1/4" main out, channel gains @ unity, channel EQs flat, all channels assigned to main mix, odd channels panned left, even channels panned right
- Main Mix Fader Unity, Channel Faders Down: -84.5 dBu
- Main Mix Fader @ Unity, Channel Faders @ Unity: -80 dBu
- THD
- 1kHz @ 15dB gain, 20Hz - 20kHz bandwidth
- Mic In to Insert Send: <0.001%
- Mic In to Main Out: <0.005%
- Attenuation / Crosstalk
- 1kHz relative to +10dBu, 20Hz - 20kHz bandwidth, mic in, 1/4" main out, gain @ unity
- Channel Mute Switch Engaged: -90 dBu
- Channel Fader Down: -88 dBu
- Frequency Response
- Mic input to main output (gain @ unity)
- +0, -1 dB, 20Hz to 50kHz
- +0, -3 dB, <10Hz to >100kHz
- EIN (mic input to insert send out, max gain)150Ω termination: -128.5 dBu 20Hz - 20kHz
- CMRR (1kHz)better than -70 dB
- Max. Levels
- Mic In: +21 dBu
- All Other Inputs: +21 dBu
- Main Mix XLR Out: +27 dBu
- All Other Outputs: +21 dBu
- Impedances
- Mic In: 2.7 kΩ
- Channel Insert Return: 2.5 kΩ
- All Other Inputs: 10 kΩ or greater
- Tape Out: < 10 Ω
- All Other Outputs: 120 Ω
- 3-Band EQ (mono channels)
- High Shelving: ±15 dB @ 12kHz
- Mid Peaking: ±15 dB sweep 100Hz - 8kHz
- Low Shelving: ±15 dB @ 80Hz
- Low Cut Filter: 18 dB/octave, -3 dB @ 100Hz
- 4-Band EQ (stereo channels)
- High Shelving: ±15 dB @ 12kHz
- Hi Mid Peaking: ±15 dB @ 2.5kHz
- Low Mid Peaking: ±15 dB @ 400Hz
- Low Shelving: ±15 dB @ 80Hz
- USB
- Format: USB 1.1
- I/O: stereo input, 4 channel output
- A/D/A: 24 bit, 44.1kHz / 48kHz
- AC Power Requirements
- Power Requirements: 65 watts
- US, JP: 100-120VAC, 50-60Hz
- Operating Temperature32°F to 104°F (0°C to 40°C)
- Dimensions
- Front Height: 1.8"
- Back Height: 6"
- Depth: 19.1"
- Width: 38"
- Weight39 pounds
