- Frequency Range
- -10 dB: 40Hz - 20,000Hz
- -3 dB: 50Hz - 20,000Hz
- Coverage (HxV)90° x 50°
- Max. SPL Peak118 dB
- Transducers
- Low Frequency: 10" with ferrite
- High Frequency: 6 x 2" silk dome tweeters
- System Power Amplification
- Rated Power: 1300 watts peak
- Low Frequency Power Amplifier
- Rated Power: 1000 watts peak
- Rated THD: <1%
- Design: Class D
- High Frequency Power Amplifier
- Rated Power: 300 watts peak
- Rated THD: <1%
- Design: Class D
- System Processing
- Voicing: 3 speaker modes
- Reverb: off, 1 (short), 2 (medium), 3 (long)
- Equalization
- Low: +5 / -15 dB @ 90Hz
- High: +5 / -15 dB @ 6kHz
- Input / Output
- Input Type
- 2x female XLR balanced
- 4x 1/4" balanced/unbalanced
- 1/4" stereo
- Mic-Line Impedance: 8 kΩ balanced
- 1/4" Hi-Z Impedance: 1 MΩ unbalanced
- Mix Out: male XLR balanced
- Mix Out Impedance: 600 Ω balanced
- Crossover Point
- Crossover Frequency: 600Hz (18 dB butterworth)
- Line Input Power
- Detachable Line Cord: ~100 - 240VAC, 50-60Hz, 110W
- AC Connector: 3-Pin IEC 250VAC, 10 A male
- Power Supply Type: switchmode
- Construction Features
- Enclosure Material: polypropylene
- Enclosure Finish: black polyurea
- Grille Material: perforated steel
- Grille Finish: powder-coated black
- Dimensions (HxWxD)26.5" x 23" x 19.5"
- Weight37 pounds
