Specifications
Dimensions
Diameter
5.25"
Voice Coil Diameter
1"
Dimensions (HxWxD)
8" x 11.2" x 6.8"
Electrical
Max Voltage Gain
51dB (mic input 1/2), 9dB (stereo input)
Rated THD
<0.05%
Universal Power Supply
100VAC-240VAC, 50-60Hz, 35VAC
Audio
Frequency Response
100Hz - 17.5kHz (-3dB), 60Hz - 22kHz (-10dB)
Max SPL
110dB @ 1m (long-term), 120dB @ 1m (peak)
Connectivity
AC Connector
3-pin IEC 250VAC
Construction
Magnet Material
neodymium
Shipping
Weight
7.6 pounds (3.4 kg)
General
Mixer Section
Input impedance, Max input level, 3-band equalization
Thru Out Mic Level Pad
-30dB
CMMR
55dB (1kHz, gain at unity)
Rated Power
100 watts
Max Power
150 watts peak
Design
Class D
