Specifications
Acoustic Performance
Frequency Response: (-10 dB) 50 Hz – 20 kHz
Frequency Response: (-3 dB):57 Hz – 20 kHz
Horizontal Coverage: 90°
Vertical Coverage: 60°
Maximum SPL Peak: 115 dB
Monitor Angle: 45°
Frequency Response: (-3 dB):57 Hz – 20 kHz
Horizontal Coverage: 90°
Vertical Coverage: 60°
Maximum SPL Peak: 115 dB
Monitor Angle: 45°
Transducers
Low Frequency: 8 in / 203 mm with ferrite
High Frequency: 1.0 in / 25 mm polymer compression driver
High Frequency: 1.0 in / 25 mm polymer compression driver
Power Amplifiers
System Power Amplification Rated Power:200 watts peak
LF Amplifier Rated Power:175 watts peak
LF Rated THD:<1%
LF Cooling:Convection
LF Design: Class D
HF Amplifier Rated Power: 25 watts peak
HF Rated THD:<1%
HF Cooling: Convection
HF Design: Class D
LF Amplifier Rated Power:175 watts peak
LF Rated THD:<1%
LF Cooling:Convection
LF Design: Class D
HF Amplifier Rated Power: 25 watts peak
HF Rated THD:<1%
HF Cooling: Convection
HF Design: Class D
System Processing
Voicing: Four speaker modes
Input / Output
Input Type: 2× Female XLR & 1/4” TRS combo + 1/8” TRS + Bluetooth
Mic-Line Impedance: 20 kΩ balanced
1/4” TRS / XLR Impedance: 20 kΩ balanced
Output Type: Male XLR Balanced (Thru)
Thru Impedance: 150 Ω balanced
Mic-Line Impedance: 20 kΩ balanced
1/4” TRS / XLR Impedance: 20 kΩ balanced
Output Type: Male XLR Balanced (Thru)
Thru Impedance: 150 Ω balanced
Bluetooth Information
Bluetooth Protocol: 5.0
Bluetooth Function: Audio Streaming and User Interface Control
Bluetooth Function: Audio Streaming and User Interface Control
Electronic Crossover
Crossover Type: 24 dB/octave
Crossover Frequency: 2.2 kHz
Crossover Frequency: 2.2 kHz
Line Input Power
Detachable line cord: 100–240 VAC, 50–60 Hz, 75W
AC Connector: 3-Pin IEC 250 VAC, 10 A male
Power Supply Type: Switchmode
AC Connector: 3-Pin IEC 250 VAC, 10 A male
Power Supply Type: Switchmode
Safety Features
Input Protection: Peak and RMS limiting, power supply and amplifier thermal protection,br>Display LEDs: Voicing Mode, Outdoor Mode, Music Ducking, Feedback Eliminator, Front LED, Bluetooth Status, Link Status, Overload, Battery Level
Battery Information
Battery Type: Lithium Ion
Battery Life: Up to 12 hours
Charge Time: 3 hours (no signal) / 4 hours (with signal)
Basic Design: Asymmetrical
Battery Life: Up to 12 hours
Charge Time: 3 hours (no signal) / 4 hours (with signal)
Basic Design: Asymmetrical
Construction Features
Enclosure Material: Polypropylene
Enclosure Finish: Black, textured finish
Grille Material: Perforated metal with weather-resistant coating
Grille Finish: Powder-coated black
Handles: One
Operating Temperature: 0–40 °C / 32–104 °F
Enclosure Finish: Black, textured finish
Grille Material: Perforated metal with weather-resistant coating
Grille Finish: Powder-coated black
Handles: One
Operating Temperature: 0–40 °C / 32–104 °F
Construction Features
Enclosure Material:::Polypropylene
Enclosure Finish: Black, textured finish
Grille Material: Perforated metal with weather-resistant coating
Grille Finish: Powder-coated black
Handles: One
Operating Temperature:0–40 °C / 32–104 °F
Enclosure Finish: Black, textured finish
Grille Material: Perforated metal with weather-resistant coating
Grille Finish: Powder-coated black
Handles: One
Operating Temperature:0–40 °C / 32–104 °F
