Martin Lighting ELP Lens Tube, Degrees: 19 | Color: White

Martin Lighting ELP Lens Tube, Degrees: 19 | Color: White

SoundPro Item: 95642 | Part Number: 9045115166

$536.00
$536.00 $536.00
Your Price Sold out
MSRP: $536.00 | MAP: $536.00

In stock and ready to ship

Log in or register for YOUR best price

Martin ELP Static Lenses work with the Martin ELP and ELP IP fixtures. Just like the fixtures themselves, they are available in black and white housing color variants.

They are available in 19°, 26°, 36° and 50° variants, and have been engineered to offer superior output and crisp image projection when combined with the Martin ELP ellipsoidal profiles.

View full details
  • PHYSICAL
    • Length: 648 mm (25.5 in.)
    • Width: 259 mm (10.2 in.)
    • Height: 254 mm (10 in.), 427 mm (16.8 in.) with bracket
    • Weight: 7.7 kg (17 lbs) body only
  • DYNAMIC EFFECTS
    • Color mixing: RGBLA
    • Color Temperature Range: 2000-10000K
    • Color selection: 26 color presets
    • Electronic dimming: 0–100%, Four dimming curve options
    • Strobe and pulse effects: Variable speed and action, random strobe
    • Electronic shutter effect: Instant open and blackout
  • CONTROL AND PROGRAMMING
    • Control options: DMX, stand-alone
    • DMX channels: 1/10/17
    • 16-bit control: Intensity, CTC, RGBLA
    • Setting and addressing: Control panel with OLED display or via RDM
    • PWM: 600-2400 Hz
    • Standalone programming: Control panel with OLED display
    • DMX compliance: USITT DMX512-A
    • RDM compliance: ANSI/ESTA E1.20
    • Transceiver: Opto-isolated RS-485
  • OPTICS
    • Light source: 91 X RGBAL Luxeon Rebel LEDs (19 Red, 24 Green, 12 Blue, 24 Lime, 12 Amber)
    • Minimum LED lifetime: 30,000 hours (to >70% luminous output)*
    • Color temperature: 2000-10000K
    • Lens tube options: 19°, 26°, 36°, 50°
    • Zoom Lens Tube Options: 15–30° and 25–50°
    • Binning: Tight color and flux binning
    • Calibration: White Point Color Calibration
    • *Figure obtained under manufacturer's test conditions
  • PHOTOMETRIC DATA
    • Light engine luminous output: 20,000 lumens
    • High Output Mode
    • Fixture luminous output: 6,900 lumens
    • CRI (Color Rendering Index): >85
    • CQS (Color Quality Scale): >90
    • TM-30 Rf (IES TM-30-15 Fidelity Index): >84
    • TM-30 Rg (IES TM-30-15 Gamut Index): >111
    • TLCI (Television Lighting Consistency Index): >85
    • CCT: 5500 K (+/- 250 K)
    • High Quality Mode
    • Fixture luminous output: 5,900 lumens
    • CRI (Color Rendering Index): >90
    • CQS (Color Quality Scale): >87
    • TM-30 Rf (IES TM-30-15 Fidelity Index): >84
    • TM-30 Rg (IES TM-30-15 Gamut Index): >106
    • TLCI (Television Lighting Consistency Index): >87
    • CCT: 6000 K (+/- 250 K)
    • * All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.
  • CONSTRUCTION
    • Housing: Die-cast aluminum
    • Color: Black or white variant
    • Protection rating: IP20
  • GOBOS AND COLOR FRAME
    • Gobo size : A size, 100 mm OD, 75 mm image*, B size, 86 mm OD, 64.5 mm image*
    • Color frame size: 159 X 159 mm (6.25 X 6.25 in.)
    • *Gobo holder not included
  • INSTALLATION
    • Mounting: Adjustable bracket
    • Location: Indoor use only
    • Orientation: Any
    • Minimum distance to combustible materials: 0.2 m (0.7 ft.)
    • Minimum distance to illuminated surfaces: 0.5 m (1.6 ft.)
  • CONNECTIONS
    • AC power in, thru: Neutrik PowerCON TRUE1
    • DMX and RDM data in/out: 5-pin locking XLR
  • ELECTRICAL
    • AC power: 100-240 V nominal, 50/60 Hz
    • Idle power (zero intensity): 5 W
    • Power supply unit: Auto-ranging electronic switch-mode
    • Half-cycle RMS inrush current at 230 V, 50 Hz: 15.0 A
    • Fixture link via PowerCON at 100-120 V: Up to 4 fixtures
    • Fixture link via PowerCON at 200-240 V: Up to 9 fixtures
    • Power consumption figures are typical, not maximum. Allow for +/- 10% variation.
  • TYPICAL POWER AND CURRENT
    • 110 V, 60 Hz: 2.4 A, 259 W, PF 0.99
    • 208 V, 60 Hz: 1.3 A, 250 W, PF 0.96
    • 230 V, 50 Hz: 1.3 A, 249 W, PF 0.95
    • 240 V, 50 Hz: 1.1 A, 249 W, PF 0.95
    • Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.
  • THERMAL
    • Cooling: Forced air (temperature-regulated, low noise)
    • Maximum ambient temperature (Ta max.): 40° C (104° F)
    • Minimum ambient temperature (Ta min.): 0° C (32° F)
    • Total heat dissipation (calculated, +/- 10%): 1000 BTU/hr. (at full intensity, full white)
  • ENVIRONMENTAL
    • RoHS: Compliant
    • REACH: Compliant
    • WEEE: Compliant
    • Proposition 65: Compliant
    • Efficacy (max output): 28 lm/W
    • LWR*: 896 lm/kg (406 lm/lb)
    • LWR = Lumen-to-Weight Ratio
  • APPROVALS
    • Global CB Certification/IECEE: IEC 60598-2-17 (IEC 60598-1)
    • EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493
    • EU EMC: EN 55015; EN 55032; EN 55103-2; EN 61000-3-2,-3; EN 61547
    • US safety: UL 1573
    • US EMC: FCC Part 15 Class B
    • Canadian safety: CSA C22.2 No. 166
    • Canadian EMC: ICES-003 Class B, ICES-005 Class B
    • Australia/NZ: RCM
