NETGEAR GSM4248PX-TAANAS M4250-40G8Xf-Poe+ Managed Switch

NETGEAR GSM4248PX-TAANAS M4250-40G8Xf-Poe+ Managed Switch

SoundPro Item: 147869 | Part Number: GSM4248PX-TAANAS

$3,695.99
$4,866.19 $3,695.99
Your Price Sold out
MSRP: $4,866.19 | MAP: $3,695.99

Usually ships in 5-7 business days

  • Total Number of Network Ports: 40
  • Uplink Port: Yes
  • Modular: Yes
  • Port/Expansion Slot Details: 40 x Gigabit Ethernet PoE+
  • Port/Expansion Slot Details: 8 x 10 Gigabit Ethernet Expansion Slot
  • Media Type Supported: Optical Fiber
  • Media Type Supported: Twisted Pair
  • Ethernet Technology: Gigabit Ethernet
  • Ethernet Technology: 10 Gigabit Ethernet
  • Network Technology: 10/100/1000Base-T
  • Network Technology: 10GBase-X
  • Number of Total Expansion Slots: 8
  • Expansion Slot Type: SFP+
  • Number of SFP+ Slots: 8
  • Layer Supported: 3
  • Networking Standards: IEEE 802.3bt
  • Networking Standards: IEEE 802.3af
  • Networking Standards: IEEE 802.3at
  • Networking Standards: IEEE 802.1as
Log in or register for YOUR best price

Introducing the NETGEAR AV Line of M4250 Switches, developed and engineered for audio/video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market, combining years of networking expertise in AV with M4300 and M4500 series with best practices from leading experts in the professional AV market. AV codecs generally use 1Gbps or 10Gbps per stream and the AV Line of M4250 targets the widespread 1Gbps codecs. PoE+, Ultra90 PoE++ and rear-facing ports ensure a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video the M4250 offers profiles for NVX, AMX, Q-SYS, NDI, Dante etc. as well as audio/video/control mixed profiles. When multiple switches are used, NETGEAR IGMP PlusTM brings automation for you to just connect them together, or with M4300 and M4500 switches.

View full details

Specifications

'General Information
Manufacturer
Netgear, Inc
Manufacturer Part Number
GSM4248PXTAANAS
Brand Name
Netgear
Product Line
AV Line
Product Series
M4250
Product Model
M4250-40G8XF-PoE+
Product Name
M4250-40G8XF-PoE+ AV Line Managed Switch
Product Type
Ethernet Switch
Interfaces/Ports
Total Number of Network Ports
40
Uplink Port
Yes
Modular
Yes
Port/Expansion Slot Details
40 x Gigabit Ethernet PoE+
8 x 10 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported
Optical Fiber
Twisted Pair
Ethernet Technology
Gigabit Ethernet
10 Gigabit Ethernet
Network Technology
10/100/1000Base-T
10GBase-X
I/O Expansions
Number of Total Expansion Slots
8
Expansion Slot Type
SFP+
Number of SFP+ Slots
8
Network & Communication
Layer Supported
3
Networking Standards
IEEE 802.3bt
IEEE 802.3af
IEEE 802.3at
IEEE 802.1as
IEEE 802.1Qav
IEEE 802.1Qat
IEEE 802.1ak
IEEE 802.3az
IEEE 802.3ad
IEEE 802.1AX
IEEE 802.1s
IEEE 802.1w
IEEE 802.1p
IEEE 802.1Q
IEEE 802.1BA
IEEE 802.3aq
IEEE 802.3x
IEEE 802.1x
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3bz
IEEE 1588v2
IEEE 1588
Management & Protocols
Manageable
Yes
Power Description
PoE (RJ-45) Port
Yes
PoE Budget
960 W
Power Source
Power Supply
Number of Power Supplies Installed
1
Power Consumption
89.20 W
Plug/Connector Type
C14
Physical Characteristics
Compatible Rack Unit
1U
Form Factor
Rack-mountable
Table Top
Miscellaneous
Package Contents
M4250-40G8XF-PoE+ AV Line Managed Switch Power Cord(s) RJ45 Straight-through Wiring Serial Console Cable to DB9 USB Type-C to USB-A 2.0 Console Cable Rubber Caps for the SFP/SFP+ Sockets Rubber Footpads for Tabletop Installation Installation Guide 2 x Regular (Short) Brackets and Screws for Two-post Rack Mount (for Front Posts) Allowing for Mounting with Ports on the Back, or Ports On the Front of the Rack 2 x Longer Brackets for Two-post Rack Mount (for Front Posts) Recessing the Switch by 2 Inches in Order to Make Room for the Cabling
Application/Usage
Enterprise
Campus
Network
IP Phone
Environmentally Friendly
Yes
Environmental Certification
RoHS
WEEE
REACH
ErP
EuP
Warranty
Limited Warranty
Lifetime
