- Transducer TypeCondenser
- Polar PatternSupercardioid
- Frequency Range 20 Hz - 20 kHz
- Rated Impedance 50 ohms
- Rated load impedance 1 kohms
- Sensitivity at 1 kHz into 1 kohm 4.5 mV/Pa ± 1 dB equ. -47 dBV
- Equivalent noise level, CCIR 1 28 dB
- Equivalent noise level, A-weighted 2 18 dB-A
- Maximum SPL for THD 0.5% 3 150 dB
- Signal-to-noise ratio, CCIR (re. 94 dB SPL) 4 66 dB
- Signal-to-noise ratio, A-weighted (re. 94 dB SPL) 5 76 dB
- Maximum output voltage 12 dBu
- Supply voltage (P48, IEC 61938) 48 V ± 4 V
- Current consumption (P48, IEC 61938) 3.5 mA
- Matching connector XLR 3 F
- Weight approx. 300 g
- Diameter 48 mm
- Length 180 mm
- Note
- 1) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
- 2) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
- 3) measured as equivalent el. input signal
- 4) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
- 5) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
