Specifications
- Transducer TypeCondenser
- Polar Patterns (selectable)Cardioid, Figure-8, Omnidirectional
- Frequency Range20 Hz - 20 kHz
- Rated Output Impedance50 ohms
- Sensitivity at 1kHz into 1kΩ10/18/9 mV/Pa (Omni/cardioid/8)
- Equivalent Noise Level, CCIR29/24/30 dB (Omni/cardioid/8)
- Equivalent Noise Level, A-Weighted16/11/17 dB-A (Omni/cardioid/8)
- Typical SPL (tube characteristic) for K<0.5%110/105/111 dB (Omni/cardioid/8)
- Typical SPL (tube characteristic) for K <5%130/125/131 dB (Omni/cardioid/8)
- Signal-to-Noise Ratio, CCIR (re. 94 dB SPL)65/70/64 dB
- Signal-to-Noise Ratio, A-Weighted (re. 94 dB SPL)65/70/64 dB
- Max. Output Voltage-1 dBu
- Supply Voltage (P48, IEC 61938)P48
- Current Consumption (P48, IEC 61938)3 mA
- Matching ConnectorXLR 3 F
- Weight17.28 oz
- Dimensions2.21" diameter x 7.87" length
