Neutrik NC3MX-B Male XLR Cable Connector
Neutrik NC3MX-B Male XLR Cable Connector
SoundPro Item: 46071 | Part Number: NC3MX-B
Usually ships in 5-7 business days
- Rugged zinc diecast shell, long lasting and durable
- Chuck type strain relief system for secure clamping of cables
- Boot with rubber gland gives high protection against bending stresses
- Coloured rings and boots available for coding and marking
- UL recognized components
The Neutrik NC3MX-B Male XLR Connector is a 3 pole male cable connector with black housing and silver contacts. This "industry standard" XLR cable connector is easy to assemble with only 4 parts and no screws. Compact design with sturdy diecast shell, fiberglass reinforced hard plastic insert and chuck type strain relief for secure clamping of all cables.
- Electrical
- Capacitance Between Contacts: ≤ 4 pF
- Contact Resistance: ≤ 3 mΩ
- Dielectric Strength: 1,5 kVdc
- Insulation Resistance: > 10 GΩ (initial)
- Rated Current Per Contact: 16 A
- Rated Voltage: < 50 V
- Mechanical
- Cable O.D.: 3.5 - 8.0 mm
- Insertion Force: ≤ 20 N
- Withdrawal Force: ≤ 20 N
- Lifetime: > 1000 mating cycles
- Wiresize: max. 2.5 mm²
- Wiresize: max. 14 AWG
- Wiring: solder contacts
- Locking Device: latch lock
- Material
- Boot: polyurethan
- Contact Plating: 0.2 µm Au hard alloy over 2 µm Ni
- Contacts: brass (CuZn39Pb3)
- Insert: polyamide (PA66)
- Locking Element: zinc diecast (ZnAl4Cu1)
- Shell: zinc diecast (ZnAl4Cu1)
- Shell Plating: black chromium
- Strain Relief: polyacetal (POM)
- Environmental
- Approvals: UL
- Flammability: UL 94 V-0
- Standard Compliance: IEC 61076-2-103
- Protection Class: IP 40
- Solderability: complies with IEC 68-2-20
- Temperature Range: -22°F to 176°F (-30°C to 80°C)
