Neutrik NL4MP-ST 4 Pole Chassis Connector
Neutrik NL4MP-ST 4 Pole Chassis Connector
SoundPro Item: 98447 | Part Number: NL4MP-ST
Usually ships in 5-7 business days
- Current rating 30 A rms
- Glass reinforced materials make it extremely robust and dependable
- Precise keyway for secure mating
- Accurate twist lock latching system
- Metal insert in locking area
- Branded with unique hologram - guarantees genuine and authentic Neutrik product
The Neutrik NL4MP-ST 4 Pole Chassis Connector's features include black D-size flange, countersunk thru holes, screw termination. This chassis connector is not airtight. The speakON panel mount connectors are the standard chassis connectors for loudspeaker / amplifier interconnections. They feature a unique metal locking system, making contact only once fully locked. The speakON receptacles are robust, versatile and easy to terminate.
Note: speakON is NOT to be used as an AC mains or power supply connector!
- Electrical
- Contact Resistance: ≤ 3 mΩ (after lifetime)
- Dielectric Strength: 4 kVdc (peak)
- Insulation Resistance: > 1 GΩ (after dampheat)
- Rated Current Per Contact: 30 A rms continuous
- Rated Current Per Contact: 40 A audiosignal, duty cycle 50 %
- Rated Voltage: 250 V ac
- Attention: speakON is NOT to be used as an AC mains or power supply connector!
- Mechanical
- Lifetime: > 5000 mating cycles
- Wiresize: 4 mm²
- Wiresize: 12 AWG
- Wiring: screw terminals
- Locking Device: quick lock
- Chassis Shape: D
- Layout: standard hole position, thru holes
- Material
- Contact Plating: 4 µm Ag
- Contacts: bronze (CuZn39Pb3)
- Shell: polyamide (PA 6 30 % GR) black
- Environmental
- Flammability: UL 94 HB
- Solderability: complies with IEC 68-2-20
- Temperature Range: -22°F to 176°F (-30°C to 80°C)
