NEXO GEO M620 Line Array Speaker | Color: White
NEXO GEO M620 Line Array Speaker | Color: White
SoundPro Item: 15586 | Part Number: GEOM620-PW
Pricing available upon request
Pricing available upon request
Usually ships in 5-7 business days
- LF: 1x6.5" 8O long excursion driver
- HF: 1x1" throat driver on a BEA/FEA optimised HR Wavesource
- Dimensions (HxWxD): 191x373x260mm
- Weight: 9.7kg
- Connectors: 2 x NL4 Speakon 4 poles
- Construction: Lightweight Polyurethane composite
- Handles: Side Handles
- Front Finish: Acoustic Fabric fitted front grille
The GEO M620 from NEXO is a full-range unit for stand-alone, curved array or line array application. Extremely compact in size (191 x 373 x 260 mm), the M620 module punches well above its weight of less than 10 kgs. Using a NEXO-designed long-excursion high-efficiency 6.5" LF driver and a 1" throat driver on a BEA/FEA optimised HR Wavesource, the M620 delivers a frequency response of 80Hz-19kHz ±3dB, with nominal peak SPL of 127dB. HF dispersion is 80° or 120° horizontal, with 20° vertical coverage,0° to 20° splay when arrayed. Using NEXO's HRW patented waveguide for optimum HF coupling between elements, the M620 performs in a variety of configurations, facilitated by a fully-integrated 3-point rigging system.
- Frequency Response80Hz – 19kHz ±3dB
- Usable Range @-6dB 75Hz – 20kHz
- Sensitivity 1W @ 1m 95dB SPL Nominal
- Nominal Peak SPL @ 1m 127dB
- HF Dispersion 80°or 120°Horizontal (CCD)
- Crossover Frequencies LF-HF: 2kHz Passive
- Nominal Impedance 8Ω
- Recommended Amplifiers 450W per box (3 boxes max in parallel on one channel amplifier)
