- Audio Circuit Typeintegrated Op-Amp with Class-A FET input
- Frequency Response20Hz - 20kHz
- THD<0.005%
- Dynamic Range100dB
- Input Impedance10KΩ
- Max. Input+10dB
- Gain52dB
- Clip Level Output+15dBu
- Output Impedance300Ω
- Equivalent Input Noise-120dBu
- Noise Floor-85dBu
- Intermodulation Distortion<0.005%
- Phase Deviation8° @ 50Hz
- Common Mode Rejection-73dB @ 55Hz
- FX Loop Input Impedance100K
- FX Loop Output Impedance3000Ω
- OutputPin 1 ground, Pin 2 (+), Pin 3 (-)
- Power15VDC / 400 mA
- XLR Configuration (follows AES spec) pin-1 ground, pin-2 (+), pin-3 (-)
