• Rapco-Horizon MIC1.K 2-Conductor 24G Microphone Cable
1 1

Rapco-Horizon MIC1.K 2-Conductor 24G Microphone Cable

Rapco-Horizon MIC1.K 2-Conductor 24G Microphone Cable

SoundPro Item: 30909 | Part Number: MIC1 (BLACK)

$190.00
$190.00 $190.00
Your Price Sold out
MSRP: $190.00 | MAP: $190.00

Usually ships in 5-7 business days

  • 2 conductors 24 AWG stranded bare copper
  • Polypropylene insulated
  • Overall serve shielded
  • PVC jacketed microphone cable
Log in or register for YOUR best price

Offering a wide varety of balanced / microphone wires ranging from small OD lavalier style cables to large OD rugged rental type designs. Varying sizes of conductors and shielding types to meet the needs of virtually all balanced audio applications both digital and analog.

View full details
  • Conductor
    • AWG Size and Stranding: 24 AWG 16 strands 36 AWG
    • Material: Bare annealed copper
  • Insulation
    • Material: Polypropylene
    • Wall Thickness: .013" nominal
    • Diameter: .050" +/- .002"
  • Color CodeCode: Blue paired with red
  • Assembly
    • Lay Length: 1 3/4" maximum left hand
    • Fillers: Jute as required
  • Shield
    • Material: Bare annealed copper serve
    • Coverage: 95% nominal
  • Jacket
    • Material: Matte finish polyvinyl chloride, color as specified
    • Colors: Black, blue, green, purple, red white, and neon blue, green, orange, pink and yellow
    • Wall Thickness: .055" nominal
    • Diameter: .230 +/- .005"
  • Markings
    • Type: Surface printing in white ink(blue on white jacket)
    • Legend: VTG AUDIO LOW NOISE – BALANCED MICROPHONE
    • CABLE, MADE IN USA
    • VTG AUDIO NEON BRITES BALANCED CABLE MADE IN USA
  • Electrical
    • Capacitance Between Conductors: 21 pF/ft @ 1 kHz
    • Capacitance Conductor to Shield: 37 pF/ft @ 1 kHz
    • Characteristic Impedance: 70 ohms @ 1 MHz
    • Resistance at 20C: 23 ohms/1000 ft.
