Specifications
Dimensions
Bit Depth
24-bit
Dimensions (LxWxH)
235x225x76 mm
Electrical
Microphone Input Impedance
4KΩ
Instrument Input Impedance
1MΩ
Power Requirements
USB-C PD (9V, 3A)
Audio
Preamplifier Gain Range
0 - 76dB
Analog Audio Output Connectivity
2 x combo jack (mic, instrument, line), 1 x 3.5 TRRS headset jack (I/O)
Sample Rate
48kHz
Connectivity
Mic Inputs
20Hz - 20kHz
Monitor Outputs
20Hz - 20kHz
Line Output Maximum Level
4dBu
Headphone Output Power
250mW
USB Interface 1
1 x 2-in/14-out multichannel device, 1 x 2-in/2-out with mix-minus
USB Interface 2
1 x 2-in/2-out with mix-minus
Network Connectivity
WiFi 802.11g/n/ac 2.4GHz and 5GHz, Ethernet 100/100
Shipping
Weight
1131g
General
Equivalent Noise
-131.5dBV (A-weighted)
Recording Storage
microSDHC, microSDXC, USB-C removable drive (exFAT — minimum 100MB/s)
Data Transfer
USB 3.0 SD card reader 130MB/s
Internal Storage (GB)
4GB (SMART pads)
OS Requirements
macOS 10.15 or later, Windows 10 Version 1803 or later, Windows 11
