Specifications
Dimensions
Size
3x2.5x1.25"
Electrical
Current Drain
60ma nominal no load 15vdc
Performance
Bandwidth
20 - 20K Hz
Connectivity
Inputs
-20 dB max XLR 1K balanced, 20 dB monitor
Outputs
1/4", and 1/8" (3.5mm) 8 ohm or greater
XLR Mic
In & Pass Thru
Phone Outputs
1/4" and 1/8"
Construction
Gain
20 dB 1/4", 50 dB XLR
Shipping
Weight
1 lb (.45 kg)
General
S/N Ratio
90 dB
Ground
Lift on XLR Thru
Mono Or Stereo
1/4" Monitor Input
Power
Power
9-18 VAC/DC, 9-24 VDC
