Specifications
RF Performance
Frequency Range
630-718 MHz (B1-B4)
Switching Bandwidth
88 MHz
Frequency Stability
< 5 ppm
Tuneability
25 kHz steps
RF Output Power (LR)
25 mW rms
RF Output Power (LD)
1 mW rms
Modulation Scheme
Digital modulation: Long Range Mode (LR) and Link Density Mode (LD)
Audio
Audio Codec (LR Mode)
SeDAC (Sennheiser Digital Audio Codec)
Audio Codec (LD Mode)
SePAC (Sennheiser Performance Audio Codec)
Audio Frequency Response (LR)
30 Hz to 20 kHz (3 dB)
Audio Frequency Response (LD)
30 Hz to 14 kHz (3 dB)
Audio Gain
0 dB to +62 dB in 3 dB steps (per capsule)
Lower Cut-Off Frequency (-3 dB)
Adjustable: 60 Hz, 80 Hz, 100 Hz, 120 Hz
Encryption
Encryption
AES 256 and Digital 9000 encryption
Dimensions
Height x Diameter
270 x 40 mm
Product Width
1.574804"
Product Height
10.629927"
Weight
Product Weight
Approx. 350 g (with BA 60 battery pack and ME 9005 microphone module)
Product Weight (lb)
0.771618 lbs
Power
Operating Time
5.5 h (with BA 60 battery pack)
Shipping
Package Weight
1.9 lbs
Package Width
2.7"
Package Length
5.4"
Package Height
13.8"
Included Items
Contents
SKM 6000 handheld transmitter, MZQ 9000 microphone clamp, quick guide, safety guide
Identifiers
MPN
701050
