Specifications
Dimensions
Dimensions
Ø 19 x 250 mm
Electrical
Min. Terminating Impedance
800 ohms
Voltage
48 +- 4V Phantom
Audio
Polar Pattern
Hypercardioid
Frequency Response
40 Hz - 20 kHz
Output Impedance
25 ohms
Sensitivity in Free Field, No Load (1kHz)
25 mV/Pa +- 1 dB
Max SPL (passive)
130 dB
General
Transducer Type
RF Condenser
Equivalent Noise Level
13 dB
Equivalent Noise Level Weighted As per CCIR
24 dB
Current Consumption
2 mA
