Sennheiser SKM 100 G4 Wireless Handheld Transmitter | Frequency: A1 (470-516 MHz)
Sennheiser SKM 100 G4 Wireless Handheld Transmitter | Frequency: A1 (470-516 MHz)
SoundPro Item: 118401
Usually ships in 5-7 business days
- Transmitter only, capsule sold separately
- Wireless handheld transmitter for audio setup
- Great for stage or studio sound applications that require optimal freedom
- Easy and flexible wireless synchronization between transmitter and receiver via infrared
- Fast frequency allocation for up to 12 receivers via new linking functionality
- Up to 20 compatible channels
- Up to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF range
- Transmission Range: up to 100 meters / 300 feet
- High RF output power (up to 30 mW) depending on country regulations
Note: Microphone Capsule Sold Separately.
The SKM 100 G4 from Sennheiser is a wireless handheld microphone transmitter. Its lightweight aluminum housing makes it perfect for gigging smaller events, while its feature set makes it a great
The SKM 100 G4 is designed for optimal compatibility with evolution wireless G4 100 Series systems. Choose from a wide variety of Sennheiser microphone capsules (e 835, e 845, e 865, e 935, e 945--sold separately) to customize the transmitter to your application or project.
This handheld transmitter is available in different frequency options.
- Frequency range
- A: 516 - 558 MHz
- A1: 470 - 516 MHz
- G: 566 - 608 MHz
- Dimensions Approx. Ø 50 x 265 mm
- Compander Sennheiser HDX
- THD, total harmonic distortion ≤ 0.9 %
- Weight (incl. batteries) approx. 450 g
- Signal-to-noise ratio ≥ 110 dBA
- RF output power Max. 30 mW
- Switching bandwidth up to 42 MHz
- Peak deviation ±48 kHz
- Nominal deviation ±24 kHz
- Operating time Typically 8 h
- Modulation Wideband FM
- Power supply 2 AA batteries, 1.5 V or BA 2015 accupack
- Current consumption
- at nominal voltage: typ. 180 mA
- with transmitter switched off: ≤ 25 μA
- Input impedance 40 kΩ
- Max. Input voltage 3 Veff
- Powering 3 V battery / 2.4 V rechargeable battery
- Transmission frequency Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
- AF frequency response 80 – 18,000 Hz
- Temperature Range -10 °C to +55 °C
- Frequency stability ≤ ±15 ppm
