- Dimensions (Ø x H)407x46mm
- Weight max. 4,9 kg (10.8lbs)
- Audio Output
- 1 x 3-pin terminal (fits Phoenix contact MCVW 1.5-3-ST-3.81)
- 1x Digital Dante Network Audio (RJ-45)
- Ethernet / Control1 x RJ-45 Ethernet Port for PoE power supply and data/control communication
- Supply voltagePoE IEEE 802.3af Class 3 or PoE IEEE 802.3at / Type 2 / Class 4 (when cascaded)
- Power consumption approx. 8W
- Safety certificationIEC/EN 62368-1 (including UL 2043 testing and compliance)
- Acoustic properties
- Transducer principle: Pre-polarized condenser microphone
- AF frequency response: 100 Hz - 16.000 Hz
- Sensitivity: 0 dBV/Pa (1020 mV/Pa)
- Signal-to-noise ratio: 77 dB (A)
- Equivalent noise level: 17 dB (A)
- Number of microphone capsules: 15
- Pick-up pattern: Beam Pattern
- Max. sound pressure level: 98 dB SPL
- Dynamic range: 81 dB (A)
- Ambient conditions
- Temperature
- Operation: 0 - 40°C (32 - 104°F)
- Storage: –10 - 60°C (14 - 140°F)
- Relative air humidity: 20 - 95%, non-condensing
- Temperature
