- Transducer TypeCondenser
- Polar PatternCardioid
- Frequency Response70 Hz - 16 kHz
- Output Impedance180 Ω
- Sensitivity (at 1kHz, open circuit voltage)–33 dBV/Pa[1] (22 mV)
- Max. SPL (1kHz at 1% THD)120 dB SPL
- Signal to Noise Ratio (referenced at 94 dB SPL)67 dB
- Dynamic Range93 dB
- Self Noise (equivalent SPL, A-weighted, typical)27 dB SPL
- Common Mode Rejection (10Hz to 100kHz)>45 dB
- Preamplifier Output Clipping Level (1% THD)-7 dBV
- Polaritypositive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
- Power Requirements11-52V DC [4] 2.0mA
