- Transducer TypeCondenser
- Polar PatternOmnidirectional
- Frequency Response20 Hz - 20 kHz
- Output ImpedanceN/A
- Sensitivity (open circuit voltage, @ 1 kHz, typical)-41 dBV/Pa [1] (9 mV/Pa)
- Maximum SPL (1 kHz at 1% THD [2])
- 2500 Ω load 107 dB SPL
- 1000 Ω load 107 dB SPL
- Signal-To-Noise Ratio [3]60 dB
- Dynamic Range (@ 1 kHz)
- 2500 Ω load: 73 dB
- 1000 Ω load: 73 dB
- Self Noise (equivalent SPL, A-weighted, typical)34 dB
- Common Mode Rejection (20 to 20,000 Hz)N/A
- Operating Temperature Range-18°C (0°F) to 57°C (135°F)
- Power Requirements+1–5 V DC (500 µA max.)
- Weight19.76 g
- Notes
- [1] 1 Pa=94 dB SPL
- [2] THD of microphone preamplifier when applied input signal level is equivalent to cartridge output at specified SPL
- [3] S/N ratio is the difference between 94 dB SPL and equivalent SPL of self noise, A-weighted
