- Transducer TypeCondenser
- Polar PatternCardioid
- Frequency Response60 Hz - 20 kHz
- Output Impedance (@ 1 kHz, typical)600 Ω
- Audio Output Level-50 dBV/Pa
- Signal-To-Noise Ratio[1] (@ 1 kHz)66 dB
- Maximum SPL[1] (1000 Ω load, @ 3% THD)145.0 dB
- Dynamic Range[1] (@ 1 kHz, 1000 Ω load)117.0 dB
- Equivalent Output Noise[1] (Typical, A-Weighted)28 dB
- Power Requirements+5 V DC (nominal), 10 V maximum (DC bias)
- Cable50 inches (1.3 m)
- ConnectorTA4F
- Net Weight1.59 oz (45 g)
- Notes
- [1]Measurements taken using RK100PK preamp set @ 0 dB using 8k bias resistor.
- * All specifications measured with a 48 VDC phantom power supply. The microphone operates at lower voltages, but with slightly decreased headroom and sensitivity
