Soundcraft Si Performer 2 Live Sound Digital Mixer
Soundcraft Si Performer 2 Live Sound Digital Mixer
SoundPro Item: 46906 | Part Number: SI PERFORMER 2
Usually ships in 5-7 business days
- 24 mono mic inputs
- 8-line inputs
- 80 channels to mix
- 2 ViSi Connect™ option card slots for 128 x 96 input/output paths
- Pre/Post selection per input per bus
- Freely assignable faders and patching
- Soundcraft FaderGlow™
- Color backlit LCD screens per fader
- GEQ on every bus
- 20 sub-group / aux busses
- 4 FX busses
- 8 Matrix busses
- LRC Mix busses
- LCR panning
- 4 Stereo Lexicon Effects engines
- Delay on inputs and outputs
- 8 Mute Groups
- 8 VCA Groups
- AES in and out
- DMX interface and control - control sound and light simultaneously
- Freely assignable insert loops
- Harman HiQnet integration
- Color touch screen interface
The Si Performer 2 from Soundcraft is a digital mixer that combines audio mixing with lighting controls for a simple solution for performance or presentation applications.
- Frequency Response (mic/line in to any output)+/-1.5dB, 20Hz - 20kHz
- THD (mic sensitivity -30dBu)<0.01% @ 1kHz
- Noise
- Residual Noise -86dBu
- Mic Input EIN 22Hz-22kHz, unweighted max. gain -126dBu (150Ω source)
- Mix Noise, Masters at Unity <-86dBu
- 1 Input to Mix at Unity Gain -84dBu
- CMRR mic @ 1kHz (max gain) -80dBu
- Crosstalk (@1kHz)
- Channel On Attenuation <120dB
- Channel Fader Attenuation <120dB
- Mic-Mic -100dB @ 1kHz, -85dB @10kHz
- Line-Line -100dB @1kHz, -85dB @10kHz
- Input Gain
- Mic Gain -5dB to 58dB integrated pad design, 1 dB steps
- Line Trim -10dB to 16dB
- Gate
- Threshold -60dBFs - -6dBfs
- Depth -60dB - -3dB
- Attack 0.1ms - 200ms
- Release 20ms -500ms
- Side-chain HPF 22Hz - 2.5kHz
- Side-chain LPF 160Hz - 20kHz
- Compressor
- Threshold -52dBfs - -6dBfs
- Ratio 1:1 - 20:1
- Attack 0.1ms - 200ms
- Release 5ms - 900ms
- Makeup Gain 0dB - 24dB
- EQ
- All Bands 22Hz - 20kHz, +/-15dB Q 6-0.3
- Shelf (HF) 800Hz - 20kHz, +/-15dB
- Shelf (LF) 20Hz - 500Hz, +/-15dB
- HPF 40Hz - 1kHz
- Delayuser adjustable delay 1sample - 500ms
- GEQ31Hz - 16kHz 1/3 octave
- Digital I/O
- AES Sample Rate Converter Range 8kHz - 200kHz
- External Word Clock In range 48kHz +/-7Hz (internal systems), +/-3Hz with stageboxes
- Word clock out jitter +/-7ns
- Analog out for 0dBfs +21.5dBu
- Converter resolution 24-bit
- DSP resolution 40-bit floating point
- Latency
- Mic In to Line Out <0.8ms
- Analogue In to AES Out <0.6ms
- AES in to Line Out <0.8ms
- AES in to AES Out <0.5ms
- Stagebox Mic In to Stagebox <0.9ms
- Input & Output Levels
- Mic Input +22dBu max
- Line Input +22dBu max
- Mix Output +21.5dBu max
- Headphones (@150Ω) 300mW (recommended impedance 75 to 200Ω)
- Input & Output Impedances
- Mic Input 3kΩ
- Line Input 10kΩ
- AES Input 110Ω
- Outputs 150Ω (balanced), 75Ω (unbalanced)
- Word Clock used as Output 50Ω
- Word Clock used as Input 4K7Ω
- DMX 120Ω
- USBmax. current 200mA
- Power
- Lamp Output12V DC 100mA max (per socket)
- Consumption (typical) <130W
- AC Input Voltage Range 88-264VAC auto sensing
- AC Frequency Range 47-63Hz
