TOA A-9120SM2 CU Modular Digital Matrix Mixer Amplifier 120W

TOA A-9120SM2 CU Modular Digital Matrix Mixer Amplifier 120W

SoundPro Item: 50084 | Part Number: A-9120SM2 CU

$1,399.00
$1,730.00 $1,399.00
Your Price Sold out
MSRP: $1,730.00 | MAP: $1,399.00

Usually ships in 5-7 business days

  • Modular I/O Architecture Accepts TOA 9000 And 900 Series Modules For Custom Configurations
  • Onboard DSP With 10-Band Parametric EQ And Up To 12 Filters Per Channel
  • 30 TOA Loudspeaker EQ Presets Speed Up System Commissioning
  • RS-232C Port Enables Native Integration With AMX And Crestron Control Systems
  • 32 Scene And 32 Paging Memories For Flexible Recall And Broadcast Zones
  • Contact-Closure Control I/O Supports External Triggering Without Additional Hardware
  • Includes Rack Mounting Hardware For Direct 2U Installation
Log in or register for YOUR best price

The TOA A-9120SM2 CU is a 2U rack-mount modular matrix mixer and power amplifier built for permanent installed audio environments such as corporate facilities, houses of worship, retail spaces, and educational campuses. Its open modular architecture accepts TOA 9000 Series and legacy 900 Series input modules across up to eight slots, letting integrators tailor the I/O configuration to each project without committing to a fixed-format chassis. The onboard 120W power amplifier supports direct 4-ohm loads as well as 25V and 70V distributed speaker lines, covering both foreground and background audio applications from a single unit.

Signal processing is handled entirely within the unit, eliminating the need for outboard DSP in most installations. Each input and output channel supports up to 12 filters plus a compressor, a 10-band parametric equalizer, high-pass and low-pass filters at 12 dB per octave, tone control, and delay up to 40ms. Thirty TOA loudspeaker EQ presets are stored onboard, accelerating commissioning time significantly. Settings are saved across 32 scene memories and 32 paging memories, which can be recalled from front-panel keys or triggered via the four contact-closure control inputs. RS-232C connectivity on a D-sub port enables third-party control from AMX, Crestron, or any RS-232-capable controller, making this unit a practical choice for integrators who need reliable, programmable system control without adding a separate DSP or control processor.

Downloads

View full details

Specifications

Audio
Rated Output
120 W
Audio Input
Max. 8 channels, modular construction (modules optional); Power amplifier input: 0 dB, 10 kΩ, RCA pin jack
Audio Output
Preamplifier output 1: 0 dB, 300 Ω, unbalanced, RCA pin jack; Preamplifier output 2: 0 dB, 600 Ω, balanced, removable terminal block (3 pins); Speaker output: removable terminal block (7 pins); (Direct) 120 W, 4 Ω, unbalanced; (Transformer) 120 W, 8 Ω/25 V/70 V, balanced
Digital Audio Signal Reference Level
-20 dBFS
Frequency Response
Power amplifier section: 20 Hz - 20 kHz, +0/-1 dB; Analog input module to speaker output: 20 Hz - 20 kHz, +1/-3 dB
Power Bandwidth
(Direct) 20 Hz - 20 kHz, 0.02% THD; (Transformer) 50 Hz - 20 kHz, 0.5% THD
Total Harmonic Distortion
Power amplifier section: 0.008% (22 kHz LPF, 1 kHz, rated power); Analog input module to speaker output: 0.01% (A-Weighted, 1 kHz, rated power)
Signal to Noise Ratio
Preamplifier output volume min.: 90 dB; Preamplifier output volume max.: 61 dB; Power amplifier section: 110 dB
Crosstalk
-64 dB or less (at 20 kHz)
Tone Control
Bass: +/-12 dB at 100 Hz; Treble: +/-12 dB at 10 kHz
Parametric Equalizer
10 bands; Frequency: 20 Hz - 20 kHz, 31 points; Variable range: +/-12 dB; Q: 0.3 - 5
Speaker Equalizer
10 (setup software includes 30 TOA speaker presets)
High-Pass Filter
-12 dB/oct; Variable frequency range: 20 Hz - 20 kHz, 31 points
Low-Pass Filter
-12 dB/oct; Variable frequency range: 20 Hz - 20 kHz, 31 points
Compressor
Depth: 1 - 5
Delay
0 - 40 ms (1 ms steps), maximum 40 ms (CH 1 + CH 2), mixer mode only
Module Slots
Analog Input (Slot 1-8)
-10 dB, 10 kΩ, unbalanced
Digital Input (Slot 1-4)
24 bit/48 kHz
MIX Output (Slot 1-8)
-14 dB, 330 Ω (CH 1 prefader output), unbalanced
Digital Output (Slot 5-7)
24 bit/48 kHz
Power Supply (Slot 1-8)
+24 V, -24 V, +6 V DC
Connectivity
RS-232C
D-sub connector (9-pin, female)
Control Input
4 inputs, no-voltage make contact; open voltage: 3.3 V DC; short-circuit current: 1 mA or less; removable terminal block (14 pins)
Control Output
4 outputs, open collector; withstand voltage: 27 V DC; control current: 50 mA; removable terminal block (14 pins)
Remote Volume
2 channels; 10 kΩ/linear taper variable resistor or 0 to +10 V DC input; removable terminal block (14 pins)
Memory
Scene/Event Memory
32
Paging Memory
32
Electrical
Power Source
120 V AC, 60 Hz
Power Consumption
150 W
Environmental
Operating Temperature
-10 C to +40 C (14 F to 104 F)
Operating Humidity
35% to 80% RH (no condensation)
Construction
Finish
Panel: aluminum, hair-line, black; Case: surface-treated steel plate, black, paint
Dimensions
Dimensions
420 x 107.6 x 355 mm (16.54" x 4.24" x 13.98")
Weight
Weight
13 kg (28.66 lbs)
Included Items
Included Accessories
Power cord 2 m (6.56 ft) x1, rack mounting bracket x2, bracket mounting screw x4, blank panel x7, blank panel mounting screw x14, removable terminal plug (3 pins) x1, removable terminal plug (7 pins) x1, removable terminal plug (14 pins) x1, CD x1
