Specifications
Electrical
Power Source
100 - 240 V AC, 50/60 Hz (via supplied AC adapter)
Rated Output
1.7 W
Current Consumption
0.2 A
Audio
Signal To Noise Ratio
73 dB or more (volume: min.); 70 dB or more (volume: max.)
MIC Input
-30 dB (0 dB = 1 V), 3.5 mm mini jack (4P), phantom power supply
Speaker Output
16 Ohm, 3.5 mm mini jack (4P)
Connectivity
Control Input
External mute input: no-voltage make contact inputs, open voltage: 9 V DC or less, short-circuit current: 5 mA or less, push-in terminal block (2 pins)
Indicators
Status LEDs
Power indicator LED, Signal indicator LED
Dimensions
Base Unit
127 x 30 x 137 mm (5" x 1.18" x 5.39") W x H x D
Sub-Unit
60 x 60 x 22.5 mm (2.36" x 2.36" x 0.89") W x H x D
Weight
Base Unit
225 g (0.5 lbs)
Sub-Unit
65 g (0.14 lbs) per piece
Environmental
Operating Temperature
0 deg C to +40 deg C (32 deg F to 104 deg F)
Operating Humidity
85 %RH or less (no condensation)
Construction
Base Unit Case Finish
ABS resin, white paint
Base Unit Panel Finish
ABS resin, black paint
Sub-Unit Finish
ABS resin, white paint
Included Items
AC Adapter
x1
Power Cord
1.8 m (5.91 ft) x1
Dedicated Cable
4-pin, 2 m (6.56 ft) x2
Metal Plate
x1
Rubber Foot For Base Unit
x4
Mounting Base
x4
Zip Tie
x4
Shipping
Package Weight
2.4 lbs
Package Dimensions
13.78" x 9.84" x 3.23"
