Shure UA844+V Antenna Distribution System | Model: UA844+V/LC
Shure UA844+V Antenna Distribution System | Model: UA844+V/LC
SoundPro Item: 95408
Usually ships in 5-7 business days
- Front-mounting antenna hardware
- Rack-mounting hardware
- External power supply
- Antenna cables for receiver connections
The UA844+ Antenna Distribution System lets you stretch the power of your antenna pairs, giving you more on-air channels in less setup time. So you can set it, forget it, and have more flexibility to make sure it all sounds perfect.
- Power Requirements14 to 18 V DC
- DC Output14 to 18 V DC (x4)
- Output Current2.5A, max., combined total from all DC outputs
- Connector TypeBNC
- Bias Voltage15 V DC (150mA, max.) (x2)
- Impedance50 Ω
- Output Intercept Point21 dBm, typical
- Output Connector Isolation30dB, typical
- Gain-1 to +1 dB, input to any output port (unused ports terminated in 50 Ω)
- Dimensions (HxWxD)1.77" x 19.02" x 6.77"
